Apiezon Vacuum Sealing, Mounting, and Etching Waxes and Q Compound

Apiezon Vacuum Sealing, Mounting, and Etching Waxes

The Apiezon range of waxes features three products including the popular Apiezon Wax W, also known as ‘Black Wax’.

All three waxes in the Apiezon range can be used as permanent or semi-permanent vacuum sealants or mounting media. Apiezon Wax W is also a perfect etch resist.

q

Available Options:

Description

Why use Apiezon Waxes? Versatile products suitable for a multitude of uses Etch resist (Wax W only) First-rate vapor pressure characteristics High purity combined with powerful gettering & clean meltdown properties Excellent waterproof media Easy to use and to remove 10 year shelf life Applications Apiezon Wax W: Hard Vacuum Sealing / Mounting Wax, Etch Resist Apiezon Wax W100: Medium Hardness Vacuum Sealant / Mounting Wax Apiezon Wax W40: Soft Vacuum Sealant / Mounting Wax Apiezon Q Compound: Vacuum Sealing Compound Apiezon Q Compound Apiezon Q Compound is an effective temporary vacuum sealant that is used as a short term solution in situations which do not allow for the immediate dismantling of a system for repair. Why use Apiezon Q Compound? Temporary vacuum sealant Versatile product suitable for a multitude of uses Excellent waterproof medium Easy to use and to remove 10 year shelf life

Typical Property Wax X Wax W100 Wax W40 Q Compound
Approximate Softening Point °C °F 80-90 176-194 50-60 122-140 40-50 104-122 40-50 104-122
Estimated Vapor Pressure @ 20°C / 68°F, torr 4.5 x 10-9 4.5 x 10-9 6 x 10-8 1 x 10-4
Temperature of Application   °C °F 130 266 110 230 90 194 Ambient
Working Temperature Range -10-75 14-168 -10-45 14-113 -10-35 14-95 -10-30 14-86
Water Permeability g/cm/hr/mm Hg @ 25°C 0.8 x 10-8 1.6 x 10-8 1.6 x 10-8 N/A
Pack N/A

250 g tin

N/A

250 g tin

N/A

1 Kg

N/A

Thermal/Electrical Properties Thermal Conductivity @ 20°C, w/m °C 0.189 0.170 0.177 N/A
Specific Heat @ 25°C, J/g 1.8 2.7 2.9 N/A
Lost Tangent 0.015 0.016 0.015 N/A
Permittivity 2.8 2.7 2.9 N/A
Volume Resistivity, Ω cm 6.31 x 10-15 1.64 x 10-15 5.06 x 10-15 N/A

MSDS Q Compound MSDS Wax W

Additional information

Unit

250g, 500g, 1kg
