Description

We offer a variety of economically priced silver coated substrates. All coatings are deposited under vacuum using electron beam evaporation. These high quality substrates are coated with 500 Å (50 nm) of silver, with a thin titanium adhesion layer (2-7 nm) between the glass and silver coating. This adhesion layer can also be replaced with chromium upon request. All substrates are pre-cleaned using an ion source for quality assurance. Glass slides are packed in a dedicated cleanroom environment and shipped in slide mailers. All coverslips are packed in a dedicated cleanroom environment and shipped in a X0 Gel-Pak box.

Applications
– Optics
– Nanotechnology
– Reflectometry
– AFM applications

Spécifications

Microscope Slides Silicon Wafers Coverslips
Type: Soda lime glass P/Boron Borosilicate glass
Density: 2.48 g/cm3 ——- 2.51 g/cm3
Refractive Index (λ=546.1 nm): 1.517 ——- 1.525
Coating Silver, Au Silver, Au Silver, Au
Coating Purity: 99.999% 99.999% 99.999%
Deposition Technique: Electron Beam Electron Beam Electron Beam
Deposition Rate: 1-2 Å/sec 1-2 Å/sec 1-2 Å/sec
Vapor Pressure: 10-6 Torr 10-6 Torr 10-6 Torr
Orientation: ——- <100> ——-
Resistivity: ——- 1-50 ohm-cm ——-
Front Surface: ——- Polished ——-
Back Surface: ——- Etched ——-



Informations complémentaires

Unit

each, 2/pk
